Product Details
＋
Mini Wall Pack, 30/20/15W, 3000/4000/5000K, 100-277V, Photocell
| Product Specifications | |
|---|---|
| Voltage | 100-277VAC |
| Lumens (lm) | 30W, 3K: 3,741 lm | 30W, 4K: 3,933 lm | 30W, 5K: 3,708 lm | 20W, 3K: 2,685 lm | 20W, 4K: 2,758 lm | 20W, 5K: 2,654 lm | 15W, 3K: 1,998 lm | 15W, 4K: 2,067 lm | 15W, 5K: 2,017 lm |
| Wattage | 30/20/15W |
| Efficacy (lm/W) | 30W/3000K = 130 lm/W, 30W/4000K = 140 lm/W, 30W/5000K = 125 lm/W, 20W/3000K = 134 lm/W, 20W/4000K = 144 lm/W, 20W/5000K = 134 lm/W, 15W/3000K = 136 lm/W, 15W/4000K = 142 lm/W, 15W/5000K = 136 lm/W |
| CCT (K) | 3000K / 4000K / 5000K |
| CRI | 80 |
| Replacement for | 70W HID |
| DLC Version | DLC Premium |
| T20 Status | Exempt |
| IP Rating | IP65 |
| Wet/Damp/Dry Location | Wet |
| IK Rating | 8 |
| FCC Compliant New | Yes |
| Dimensions (L x W x H) | L: 5 13/16" (147mm), W: 3 1/16" (78mm), H: 8 9/16" (218mm) |
| Housing Color | Dark Bronze |
| Lens Material New | Polycarbonate (PC) |
| Ambient Temp Range | -40F to 113F (-40C to 45C) |
| Driver Surge Protection (kV) new | L/N-PE: 2.5kV, L-N: 2.5kV |
| Auxiliary Output | N/A |
| General Warranty | 5 Years |
